Rheem® Endeavor® Line Classic® Series iM RP14AY24AJ2NA Heat Pump, 2 ton, R-454B Refrigerant, 24000 Btu/hr Cooling BTU
Rheem® Endeavor® Line Classic® Series iM RP14AY24AJ2NA Heat Pump, 2 ton, R-454B Refrigerant, 24000 Btu/hr Cooling BTU
Manufacturer: Rheem Manufacturing
Brand: Rheem®
Part #: 94664
MPN: RP14AY24AJ2NA
CPN:
| BTU Cooling Rating | : | 24000 Btu/hr |
| BTU Heating Rating | : | 22800 Btu/hr |
| Compressor Type | : | Scroll |
| Depth | : | 29-3/4 in |
| EER2 | : | 9 |
| Energy Star Certified | : | Yes |
| HSPF2 | : | 7.5 |
| Height | : | 25 in |
| Liquid Line Size | : | 3/8 in |
| Minimum Circuit Ampacity (MCA) | : | 16 A |
| Model Number | : | RP14AY |
| Number of Rows | : | 1 |
| Number of Stages | : | 2 |
| Packaged Depth | : | 32.38 in |
| Packaged Height | : | 26.5 in |
| Packaged Width | : | 32.38 in |
| Phase | : | 1 ph |
| Product Family | : | Endeavor® Line Classic® Series iM |
| Product Weight | : | 153 lb |
| Refrigerant Type | : | R-454B |
| SEER2 | : | 14.3 |
| Shipping Weight | : | 160 lb |
| Sound Level | : | 73 dB |
| Suction Line Size | : | 3/4 in |
| Tonnage | : | 2 ton |
| Voltage Rating | : | 208-230 V |
| Width | : | 29-3/4 in |
Rheem® Endeavor® Heat Pump, R-454B Refrigerant, 24000 Btu/hr Cooling, 22800 Btu/hr Heating, 2 Stages, 14.3 SEER2, 9 EER2, 7.5 HSPF2, 73 dB Sound Level, 208-230 V, 1 ph Phase, Scroll Compressor, 3/8 in Liquid Line, 3/4 in Suction Line, 25 in Height, 29-3/4 in Width
Swept Wing Fan Technology: Features quieter operation and improved unit acousticsTwo-Stage Scroll Compressor: Features two speeds (high and low) of cooling and heating, providing more precise temperature control, lower humidity and greater efficiency when compared to single stage compressors Inverted Reversing Valve: Allows for faster heat transfer with gravity assist shifting and reduced joint stress for increased reliability PlusOne® Expanded Valve Space: 3 in. - 4 in. - 5 in. service valve space-provides a minimum working area of 27-square inches for easier access PlusOne® Triple Service Access: 15 in. wide, industry leading corner service access, two fastener, removeable corner and individual louver panels-makes repairs easier and faster
